The Blue LED Strip is an energy-efficient, flexible linear lighting fixture that uses advanced semiconductor technology to emit a pure blue spectrum.
Using InGaN semiconductor chip, central wavelength 465±5nm
Spectral half width 25nm, color purity reaches more than 95% of NTSC standard
Main wavelength deviation is controlled within ±3nm
Single LED luminous flux 12-15lm@20mA
Brightness per meter 800-1600lm
Forward voltage 3.0-3.4V, power consumption per meter 6-18W
The substrate uses 1oz thick copper foil flexible circuit board
LED spacing 6-8mm evenly distributed
Minimum bending radius can reach 20mm
Insulation resistance＞100MΩ
Withstand voltage test passed 1500VAC/minute
Compliant with IEC624 71 Photobiological safety standards
Working temperature range -40℃～+85℃
Protection level IP67 (waterproof)
UV aging test > 5000 hours
L70 life > 50,000 hours
Light decay < 5%/1000 hours
Failure rate < 0.1%/1000 hours
Cutting unit length 50mm
Maximum series length 15 meters
Can withstand maximum tension 25N
Configured in the aquaculture pond lighting system, it helps promote the growth of specific algae
Integrated in special effects lighting equipment, it helps create deep-sea visual effects
Used as a supplementary light source, it helps to regulate the light form of plants
